| 브랜드 이름: | Raymo |
|---|---|
| 인증: | CE/RoHs/REACH/ISO9001:2015 |
| Model Number: | RM-J30J |
| 문서: | J30J Miniature Rectangular ...es.pdf |
| Minimum Order Quantity: | 1 Piece |
| 가격: | 5-15 USD |
| Packaging Details: | CTN |
| Delivery Time: | 3-4 Weeks |
| 지불 조건: | T/T, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 5000PCS Per Month |
| 내 전압: | 500VAC | 케이블 길이: | 요구대로 |
|---|---|---|---|
| 접촉 핀: | 9, 15, 21, 25, 31, 37, 51, 66, 74, 100 핀 | 신청: | 전자 장비 |
| 중심 지휘자: | 구리 합금, 금도금 | 온도 범위: | -55~+125℃ |
| 전압 등급: | 250V | 메이팅 사이클: | 500 번 |
| 강조하다: | J30J MIL-Spec connector 500VAC,J30J series connector 500 mating cycles,MIL-Spec connector with 500VAC rating |
||
| Attribute | Value |
|---|---|
| Withstanding Voltage | 500VAC |
| Contact Pin Options | 9, 15, 21, 25, 31, 37, 51, 66, 74, 100 Pins |
| Center Conductor | Copper Alloy, Gold Plating |
| Temperature Range | -55～+125 ℃ |
| Voltage Rating | 250V |
| Mating Cycle | 500 Times |
| Parameter | Specification |
|---|---|
| Mating Cable | AFR-250, White Wire 0.1~0.15mm² |
| Type | Connector |
| Application | Electronic Equipment |
| Certifications | CE, RoHs, REACH, ISO9001:2015 |
