| 브랜드 이름: | Raymo |
|---|---|
| 인증: | CE/RoHs/REACH/ISO9001:2015 |
| Model Number: | RM-2PM |
| Minimum Order Quantity: | 5 |
| 가격: | 1-10USD |
| 배달 시간: | 2-3 주 |
| 지불 조건: | T/T, Western Union, MoneyGram, D/A, D/P. |
| 공급 능력: | 한 달에 5000 개의 PC |
| 짝짓기주기: | 500 번 | 셀 크기: | 14/18/22/24/27/30/33/36/39/42/45 |
|---|---|---|---|
| 특징: | 플러그 앤 플레이 | 연락처: | 47/8/10/19/20/22/24/30/32/42/45/50 |
| 정격 전류: | 5-30A | 연결 방법: | 나사접속 |
| 접촉 자료: | 은/금 도금된 구리 | 연결기 시리즈: | 2PM 2PX 커넥터 |
| 강조하다: | 2PM connector silver gold plated,2PM connector 500 mating cycles,2PM connector copper contacts |
||
The 2PM Connector is a high-quality circular connector designed for demanding industrial applications. Featuring durable copper contacts with silver/gold plating and rated for 500 mating cycles, this connector delivers reliable performance in harsh environments.
| Attribute | Value |
|---|---|
| Mating Cycles | 500 Times |
| Shell Size Options | 14/18/22/24/27/30/33/36/39/42/45 |
| Contact Configuration | 47/8/10/19/20/22/24/30/32/42/45/50 |
| Rated Current | 5-30A |
| Connection Method | Thread Connection |
| Contact Material | Copper with Silver/Gold Plating |
| Series | 2PM 2PX Connectors |
| Parameter | Specification |
|---|---|
| Material | Aluminum Alloy |
| Temperature Range | -60°C to 200°C |
| Shape | Circular |
| Size | Small |
The 2PM Connector is ideal for demanding industrial environments including:
